Features
Identification
- Symbols: Each element has a symbol based on the NationalStandard for diagramming moving part logic control
- Mounting: Elements have 5/8" (15.9mm) bolt extensions.Mounting hardware and seals provided with each element
- TestPorts: Many elements have 1/8" NPT ports connected to the"C" (output) port. These can be used as optional outputports, or as test ports
- Port Identification: Letters castinto the cove and base of each element correspond to input andoutput designations
Mounting
- Indiviual Elements
- Circuit Board Construction
- Function Base Assembly Method
- Back TubulationConstruction
